Auto-Open/Close Function For Driver-Side

Disconnect the negative battery terminal. (See NEGATIVE BATTERY TERMINAL DISCONNECTION/CONNECTION .)
Remove the rear door trim. (See REAR DOOR TRIM REMOVAL/INSTALLATION .)
Disconnect the front power window motor connector.

Apply battery positive voltage and connect the ground to rear power window motor terminals E and F, and then inspect the rear power window motor operation.

B+ Terminal	Ground Terminal	Operation
E	F	Close
F	E	Open

Fig 1: Connecting Ground To Front Power Window Motor Terminals E And F And Connector End View

Courtesy of MAZDA MOTORS CORP.

If the rear power window motor does not operate as indicated in the table, replace it. (See REAR POWER WINDOW MOTOR REMOVAL/INSTALLATION .)
