| AUDIO button |
Switches the display screen of the center display to the entertainment screen. |
| HOME button |
- Switches the display screen of the center display to the home screen.
- When the HOME button is pressed and held, the display screen of the center display switches to the Apple CarPlay™ home screen.
- When the HOME button is pressed and held, the display screen of the center display switches to the Android Auto™ home screen.
|
| NAV button (With car-navigation system) |
Switches the display screen of the center display to the navigation screen. |
| BACK button |
Switches to the screen directly previous to the currently displayed screen. |
| FAVORITES button |
- Displays favorites in the center display.
- When the button is long-pressed with the screen to be added to the favorites displayed, the target is added to the favorites.
|
| Volume dial |
- When the volume dial is rotated, the volume can be adjusted.
- When the volume dial is pressed, the volume can be muted. Pressing again after muting returns to previous volume level.
|
| Commander knob (tilt ) |
Moves the selection area on the center display screen. The selection area can be tilted in the lateral direction for left/right, and the longitudinal direction for forward/back. |
| Commander knob (rotation) |
Moves the selection area on the center display screen. The selection area moves according to the rotation direction. |
| Commander knob (click ) |
- Switches to the selected menu screen.
- Launches the selected menu.
|
