| 1 |
PCM (BARO sensor, PCM temperature sensor)
(See PCM REMOVAL/INSTALLATION .)
(See PCM INSPECTION .)
(See CONFIGURATION
.)
(See BAROMETRIC PRESSURE (BARO) SENSOR REMOVAL/INSTALLATION .)
(See BAROMETRIC PRESSURE (BARO) SENSOR INSPECTION .) |
| 2 |
Ion sensor
(See ION SENSOR REMOVAL/INSTALLATION .)
(See ION SENSOR INSPECTION .) |
| 3 |
Low fuel pressure sensor/Fuel temperature sensor
(See LOW FUEL PRESSURE SENSOR/FUEL TEMPERATURE SENSOR REMOVAL/INSTALLATION .)
(See LOW FUEL PRESSURE SENSOR INSPECTION .)
(See FUEL TEMPERATURE SENSOR INSPECTION .) |
| 4 |
Intake CMP sensor
(See CAMSHAFT POSITION (CMP) SENSOR REMOVAL/INSTALLATION .)
(See CAMSHAFT POSITION (CMP) SENSOR INSPECTION .) |
| 5 |
Boost pressure sensor
(See BOOST PRESSURE SENSOR REMOVAL/INSTALLATION .)
(See BOOST PRESSURE SENSOR INSPECTION .) |
| 6 |
Boost air temperature sensor
(See BOOST AIR TEMPERATURE SENSOR REMOVAL/INSTALLATION .)
(See BOOST AIR TEMPERATURE SENSOR INSPECTION .) |
| 7 |
TP sensor
(See THROTTLE POSITION (TP) SENSOR REMOVAL/INSTALLATION .)
(See THROTTLE POSITION (TP) SENSOR INSPECTION .) |
| 8 |
Exhaust gas pressure sensor
(See EXHAUST GAS PRESSURE SENSOR REMOVAL/INSTALLATION .)
(See EXHAUST GAS PRESSURE SENSOR INSPECTION .) |
| 9 |
MAP sensor/IAT sensor No. 2
(See MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR/INTAKE AIR TEMPERATURE (IAT) SENSOR NO. 2 REMOVAL/INSTALLATION .)
(See MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR INSPECTION .)
(See INTAKE AIR TEMPERATURE (IAT) SENSOR INSPECTION .) |
| 10 |
High fuel pressure sensor
(See HIGH FUEL PRESSURE SENSOR REMOVAL/INSTALLATION .)
(See HIGH FUEL PRESSURE SENSOR INSPECTION .) |
| 11 |
KS
(See KNOCK SENSOR (KS) REMOVAL/INSTALLATION .)
(See KNOCK SENSOR (KS) INSPECTION .) |
| 12 |
Current sensor
(See CURRENT SENSOR REMOVAL/INSTALLATION .) (See CURRENT SENSOR INSPECTION .) |
| 13 |
Exhaust CMP sensor
(See CAMSHAFT POSITION (CMP) SENSOR REMOVAL/INSTALLATION .)
(See CAMSHAFT POSITION (CMP) SENSOR INSPECTION .) |
| 14 |
ECT sensor No. 1
(See ENGINE COOLANT TEMPERATURE (ECT) SENSOR REMOVAL/INSTALLATION .)
(See ENGINE COOLANT TEMPERATURE (ECT) SENSOR INSPECTION .) |
| 15 |
Wastegate valve position sensor
(See WASTEGATE VALVE POSITION SENSOR REMOVAL/INSTALLATION .)
(See WASTEGATE VALVE POSITION SENSOR INSPECTION .) |
| 16 |
ECT sensor No. 2
(See ENGINE COOLANT TEMPERATURE (ECT) SENSOR REMOVAL/INSTALLATION .)
(See ENGINE COOLANT TEMPERATURE (ECT) SENSOR INSPECTION .) |
| 17 |
MAF sensor/IAT sensor No. 1
(See MASS AIR FLOW (MAF) SENSOR/INTAKE AIR TEMPERATURE (IAT) SENSOR NO. 1 REMOVAL/INSTALLATION .)
(See MASS AIR FLOW (MAF) SENSOR INSPECTION .)
(See INTAKE AIR TEMPERATURE (IAT) SENSOR INSPECTION .) |
