Removal & Installation
WARNING: This page is about a different car, the 1996 Mercedes-Benz E320 and 1996 Mercedes-Benz E300. However, it is still accessible from the selected car via links, so may be relevant.
Disconnect negative battery cable. Remove cover on control module box, located in right rear of engine compartment. See Fig 1. Disconnect harness connector "B" from combination control module. Pull connector "B" harness out of control module box. Open safety catch on control module. Pull control module out of guide rail. Disconnect remaining harness connectors and remove control module. To install, reverse removal procedure.
