Performing basic programming - AR00.19-P-0200C

MODELS 202, 208

  Adjusting
1 Set time on instrument cluster IMPORTANT See Operating Instructions
2 Set clock of stationary heater IMPORTANT See Operating Instructions
3 Normalize side power windows IMPORTANT Refer also to operating instructions.
REFER TO BASIC KNOWLEDGE   IMPORTANT Model 202 as of 1.6.97 GF72.29-P-4003A
4 Activate steering angle sensor IMPORTANT Electronic stability program (ESP) Code (472a). AR46.10-P-0300-01A
    IMPORTANT Refer also to operating instructions.
5 Synchronize sliding/pop-up roof IMPORTANT Refer also to operating instructions.
REFER TO BASIC KNOWLEDGE   IMPORTANT Model 202 as of 1.6.97, Model 208 (except 208.435/445/447/465 as of 1.3.97) GF77.20-P-3002A
6 Code radio Becker 2000. AR82.60-P-7502-01A
    MB
IMPORTANT Refer also to radio operating instructions.		 AR82.60-P-7502-01B
