Spark Plug Check And Cleaning

CAUTION:
  • Do not attempt to adjust the gap of the iridium plug.
  • Cleaning of the iridium plug may result in damage to the iridium tips. Therefore, if carbon deposits must be removed, use a plug cleaner and complete cleaning within 20 seconds to protect the electrode. Do not use a wire brush.

Check the plug gap and replace if the limit is exceeded.

Standard value: 0.7 -- 0.8 mm (0.028 -- 0.031 inch)

Limit: 1.0 mm (0.039 inch)

Fig 1: Checking Plug Gap
G00877783Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
