Sensor Rotor: Removal

  1. Remove the front wheel hub. Refer to "REMOVAL AND INSTALLATION ".
  2. Remove the sensor rotor using suitable puller.
    Fig 1: Removing Sensor Rotor Using Suitable Puller
    G02523229Courtesy of NISSAN MOTOR CO., U.S.A.
