Engine Compartment

Fig 1: Engine Room Compartment Components Location (2 Of 2)

Courtesy of NISSAN NORTH AMERICA, INC.

Engine front side

No.	Component	Function
	PCV valve	The positive crankcase ventilation (PCV) valve is provided to conduct crankcase blow-by gas to the intake manifold.
	Fuel injector	FUEL INJECTOR
	Knock sensor	KNOCK SENSOR
	Engine oil temperature sensor	ENGINE OIL TEMPERATURE SENSOR
	Crankshaft position sensor (POS)	CRANKSHAFT POSITION SENSOR (POS)
	Engine oil pressure sensor	ENGINE OIL PRESSURE SENSOR
	Engine coolant temperature sensor	ENGINE COOLANT TEMPERATURE SENSOR
	Camshaft position sensor (PHASE)	CAMSHAFT POSITION SENSOR (PHASE)
	Exhaust valve timing control position sensor	EXHAUST VALVE TIMING CONTROL POSITION SENSOR
	Ignition coil (with power transistor)	IGNITION COIL WITH POWER TRANSISTOR
	Exhaust valve timing control solenoid valve	EXHAUST VALVE TIMING CONTROL SOLENOID VALVE
	Intake valve timing control solenoid valve	INTAKE VALVE TIMING CONTROL SOLENOID VALVE
