Full Electric Choke System: Servicing

CAUTION: DO NOT immerse choke assembly in any cleaning fluids, as damage to the electric heating element and switch could result.
NOTE: For 1980, all Horizon and Omni models are equipped with chokes that are non-adjustable due to choke cover retaining ring being riveted to the choke housing.
Fig 1: Schematic of Full Electric Choke System (Omni & Horizon)
G09343084Courtesy of CHRYSLER GROUP, LLC
