Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the rear shelf trim panel. Refer to TRIM PANEL REPLACEMENT - REAR WINDOW SHELF in Interior Trim.
  2. Loosen the audio amplifier bolts.
  3. Open the rear compartment.
  4. Lower the audio amplifier bolts away from the openings in the rear window panel, as shown. Disengage the tabs from the slots in the rear window panel.
  5. Disconnect the electrical connectors from the audio amplifier.
  6. Remove the audio amplifier.
    Fig 1: Disconnecting Electrical Connectors From Audio Amplifier
    G01503383Courtesy of GENERAL MOTORS CORP.
