Scan Tool Data Definitions
WARNING: This page is about a different car, the 2002 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.
Cruise Control Active: Displays Disengaged or Engaged. The status of the cruise engaged signal. The cruise control module grounds the circuit when cruise control is on.
Cruise Inhibit Reason: Displays the last cruise control disengage. There are 20 possible causes for cruise control disengagement.
Cruise Inhibit Signal Command: Displays ON or OFF, Indicates if the PCM is commanding the cruise control module to inhibit cruise control operation.
TCC/Brake Pedal Switch: Displays ON or OFF. The current status of the TCC/Brake switch.
