Installation Procedure

WARNING: This page is about a different car, the 2003 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Reading Lamp Cover
    GM980449Courtesy of GENERAL MOTORS CORP.
  1. Position the OnStar® microphone in the cover.
  2. Install the microphone by snapping into place.
  3. Connect the wiring harness.
  4. Snap the cover to engage the snap tabs.
  5. Slide the cover rearward to engage the rear hooks.
  6. Snap the reading lamp cover into place.
