Installation Procedure

    Fig 1: View Of Front Door Lock Switch Plate (Aztek)
    GM709383Courtesy of GENERAL MOTORS CORP.
  1. Install the front door window control switch (2) into the front door window switch plate.
  2. Connect the electrical connectors to the front door window control switch.
  3. Install the front door window control switch plate to the front door panel pressing into place until fully seated.
