Installation Procedure

    Fig 1: View Of Air Cleaner Intake Duct
    GM1657025Courtesy of GENERAL MOTORS CORP.
  1. Position the air cleaner intake duct.
    2. CAUTION: Refer to Fastener Caution .
  2. Install the air cleaner intake duct bolt and tighten to 10 N.m (89 lb ft).
  3. Install the air cleaner intake duct retainer.
  4. Install the right front fender liner. Refer to Front Fender Liner Replacement .
  5. Install the right front tire and wheel. Refer to Tire and Wheel Removal and Installation .
