Removal & Installation: Installation
- Before installing cap, remove cable for No. 3 cylinder to provide access to clamping hook. Align distributor cap with its locking boss facing up.
- Align clamping hooks in distributor cap so they are positioned horizontally and facing toward left side when viewed from front. Guide hooks into both slots, and engage distributor cap by turning back and forth slightly. Watch position of dust cap.
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
- Turn both clamping hooks against left stop. Press in on hooks far enough so that they can be turned counterclockwise approximately 1/4 turn and engage when released.
- Check that distributor cap fits tightly. Be sure hooks are firmly engaged. Reinstall cable for No. 3 cylinder on distributor cap.
