Main components

Fig 1: Identifying ABS Main Components
G03578852Courtesy of SAAB-SCANIA OF AMERICA, INC.
  1. Hydraulic unit, complete with control module, valve block and return pump (547)
  2. ABS warning lamp on MIU (540)
  3. Wheel sensor, FR (298FL)
  4. Wheel sensor, FL (298FR)
  5. Wheel sensor, RR (298RR)
  6. Wheel sensor RL (298RL)
