Horns Connector End Views
Horn
Courtesy of GENERAL MOTORS CORP.
Connector Part Information
12052644
2-Way F Metri-Pack 150 Series Sealed (L-GY)
Pin
Wire Color
Circuit Number
Function
1
D-GN
29
Horn Control
2
BK
150
Ground
Courtesy of GENERAL MOTORS CORP.
