DTC P1526: TP Sensor Learn Not Done After Reprogramming
>>
Diagnostic Procedure
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
Diagnostic Procedure
Fig 1: DTC P1526: TP Sensor Learn Not Done After Reprogramming (Steps 1-6)
Courtesy of GENERAL MOTORS CORP.
Fig 2: DTC P1526: TP Sensor Learn Not Done After Reprogramming (Steps 7-15)
Courtesy of GENERAL MOTORS CORP.
