Removal Procedure

    Fig 1: Identifying MAF/IAT Sensor Electrical Connector
    GM1592530Courtesy of GENERAL MOTORS CORP.
  1. Disconnect the mass air flow (MAF)/intake air temperature (IAT) sensor electrical connector (1).
    2. Fig 2: View Of MAF/IAT Sensor
    GM1594069Courtesy of GENERAL MOTORS CORP.
  2. Remove the MAF/IAT sensor screws.
  3. Remove the MAF/IAT sensor.
