On-Vehicle Inspection

  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
    CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
  2. REMOVE EFI RELAY (Marking: EFI)
    1. Remove the engine room relay block cover.
    2. Remove the EFI relay from the engine room relay block.
  3. INSPECT EFI RELAY
    1. Measure the resistance of the EFI relay.

      Standard resistance

      TESTER CONNECTION SPECIFIED CONDITION CHART

      Tester Connection Specified Condition
      3 - 5 10 kΩ or higher
      3 - 5 Below 1 Ω (when battery voltage is applied to terminals 1 and 2)

      If the result is not as specified, replace the EFI relay.

  4. INSTALL EFI RELAY
  5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  6. PERFORM INITIALIZATION
    1. Perform initialization (see INITIALIZATION ).
      NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
      Fig 1: Installing EFI Relay
      G04153232Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
