Sliding Roof: Notes

Fig 1: Sliding Roof System Wiring Diagram (1 Of 2)
G08759404Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Sliding Roof System Wiring Diagram (2 Of 2)
G08759405Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
