Park / Neutral Position Switch: Installation

INSTALL PARK/NEUTRAL POSITION SWITCH ASSEMBLY
1. Install the switch to the manual valve shaft.
2. Temporarily install the 2 bolts.

  Fig 1: Locating Manual Valve Shaft Bolts
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
3. Place a new lock plate and tighten the nut.
  Torque: 6.9 N*m (70 kgf*cm, 61 in.*lbf)
4. Temporarily install the control shaft lever.

  Fig 2: Locating Lock Plate And Nut
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
5. Turn the lever counterclockwise until it stops, then turn it clockwise 2 notches.
6. Remove the control shaft lever.

  Fig 3: Turning Control Shaft Lever
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
7. Align the groove with the neutral basic line.
8. Hold the switch in position and tighten the 2 bolts.
  Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)

  Fig 4: Aligning Groove With Neutral Basic Line
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
9. Using a screwdriver, stake the nut with the lock plate.

  Fig 5: Staking Nut With Lock Plate
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
10. Install the control shaft lever, with the washer and nut.
  Torque: 13 N*m (132 kgf*cm, 10 ft.*lbf)
11. Connect the switch connector.
INSTALL TRANSMISSION CONTROL CABLE ASSEMBLY
1. Install the control cable and clip to the control cable bracket with the clip.

  Fig 7: Identifying Control Cable And Clip
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. Temporarily install the control cable to the control shaft lever with the nut.

Fig 8: Locating Control Shaft Lever Nut

INSTALL ENGINE UNDER COVER LH
ADJUST SHIFT LEVER POSITION
1. Adjust the shift lever position (see ADJUSTMENT ).
INSPECT SHIFT LEVER POSITION
1. Inspect the shift lever position (see ADJUSTMENT ).
INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY
1. Inspect the park/neutral position (see INSPECTION ).
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
PERFORM INITIALIZATION
1. Perform initialization (see INITIALIZATION ).
  NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
