Breaker Arm Spring Tension

Place hook end of spring scale as close as possible to the movable breaker point. Pull scale at a right angle (90 degrees) to the movable arm and note reading just as points begin to open.

Fig 1: Typical Vacuum Advance System
G09350967Courtesy of NOT AVAILABLE
