Control Units
CONTROL UNITS LOCATION
| Component | Location |
|---|---|
| Cruise Control Unit | Under right side of instrument panel. See Figure . |
| ECU Control Unit (Inj.) | Under left side of instrument panel. See Figure . |
| Electronic Control Module (Carb.) | Under left side of instrument panel. |
| EGI Control Unit (Ignition) | Under left side of instrument panel. See Figure . |
| Fuel Pump Control Unit | Under left side of instrument panel. |
| Knock Control Unit | Under left side of instrument panel. |
| Power Window Control Unit | Under front passenger's seat. See Figure . |
| Vehicle Height Control Unit | Under driver's seat. |
