Base To Power Pattern Changeover
BASE TO POWER PATTERN CHANGEOVER
| Select lever | D and 3 ranges |
|---|---|
| Accelerator depression speed | Greater than each set value |
The TCM has16 matrix cells corresponding different throttle opening and vehicle speeds, as shown below. Each cell is given a specific accelerator depression speed at which a Base to Power pattern changeover should occur.
When the accelerator depression speed exceeds the value given for any of the cells, the TCM selects the Power pattern.
