Rear Window Defogger Switch: Removal

  1. Remove center air vent grille. Refer to REMOVAL , Air Vent Grilles
  2. Pull out switch and disconnect the connector.
    Fig 1: Removing Switch & Disconnect Connector
    G02863902Courtesy of SUBARU OF AMERICA, INC.
