System Specifications

TIMING CHAIN COVER
Tightening torque 6.6 Nm (0.67 kgf-m, 4.8 ft-lb)

Note: Tighten the bolts in the numerical sequence shown in figure.




CRANKSHAFT PULLEY/TIMING GEAR
Pulley Bolt 178 Nm (18.1 kgf-m, 131 ft-lbs)




TIMING CHAIN
