Accelerator Pedal: Removal

  1. Disconnect the ground cable from battery.
    Fig 1: Identifying Battery Ground Cable
    G06648603Courtesy of SUBARU OF AMERICA, INC.
  2. Disconnect the connector (A).
  3. Remove the nut (B) securing accelerator pedal assembly and remove the accelerator pedal assembly.
    Fig 2: Identifying Connector And Nut
    G06648604Courtesy of SUBARU OF AMERICA, INC.
