Horn System: Horn: Installation

Install each part in the reverse order of removal.

CAUTION: Install the bumper face so that the under cover front end (b) comes inside the front bumper face (a).

Fig 1: Identifying Proper And Improper Bumper Installation Position

Courtesy of SUBARU OF AMERICA, INC.

Tightening torque:

Horn assembly: 18 N.m (1.84 kgf-m, 13.3 ft-lb)
