Fuel Injector 2

Fig 1: Identifying Fuel Injector 2 Related Components With Torque Specification

Courtesy of SUBARU OF AMERICA, INC.

Tightening torque: N.m (kgf-m, ft-lb)

T1: 6.4 (0.7, 4.7)

T2: 19 (1.9, 14.0)

T3: 21 (2.1, 15.5)

T4: 25 (2.5, 4.7)
