Fuel Pump Relay: Removal

  1. Disconnect the ground cable from battery. Ref. to REPAIR CONTENTS>NOTE>BATTERY .
  2. Remove the fuel pump relay from the main fuse box.
G11252917Courtesy of SUBARU OF AMERICA, INC.
