Front Wheel Speed Sensor: Removal
CAUTION:
If water or oil contacts the connector terminal of front wheel speed sensor, replace it with a new part.
- Disconnect the ground terminal from battery sensor. Ref. to REPAIR CONTENTS>NOTE>BATTERY .
- Remove the center exhaust pipe (rear). Ref. to EXHAUST (H4DOTC)>Center Exhaust Pipe>REMOVAL>CENTER EXHAUST PIPE (REAR) .
- Disconnect the connector and remove the front wheel speed sensor.NOTE: Prepare the container for draining of engine oil.
