Car Computer - HW4 - Remove And Install: Notes

Last modified: 07/09/2023 10:52:53

Courtesy of TESLA, INC.

NOTE: See Personal Protection to make sure to wear proper PPE when performing below procedure.

Revision History:

2023-09-06: Cleaned up procedure.

WARNING: This procedure is a DRAFT, although it has been validated. Warnings and Cautions might be missing. Follow safety requirements and use extreme caution when working on or near high voltage systems and components. Provide corrections and feedback to ServiceDevelopment@teslamotors.com.

Special tool required:

1135762-00-A Car Computer Fluid Port Plug
1119171-00-A Pick Miniature Soft Grip 90 degree tip 6 in
