Four Wheel Alignment Check and Adjust: Notes
Last modified: 04/01/2024 09:37:57
NOTE:
See Personal Protection
to make sure wearing proper PPE when performing the below procedure.
Revision History:
- 2023-12-04: Revised procedure to be in line with latest PDS validation.
- 2023-06-09: Added cycle suspension ride height to High and then back to Medium when vehicle is on alignment rack with the pins pulled from the turn plates.
- 2023-07-19: Added Service Mode instructions.
NOTE:
This procedure assumes the vehicle suspension is operating as intended. If needed, SC-19-00-007 - General Vehicle Inspection can be performed.
