Drive Unit - Front - Remove And Install: Notes
Last modified: 04/10/2023 10:28:08
NOTE:
See Personal Protection
to make sure proper PPE is worn when performing the below procedure.
Revision History:
- 2023-08-02: Added steps to disconnect frunk harness from front drive unit connector and remove ground strap.
WARNING:
This procedure is a DRAFT, although it has been validated. Warnings and Cautions might be missing. Follow safety requirements and use extreme caution when working on or near high voltage systems and components. Provide corrections and feedback to ServiceDevelopment@teslamotors.com.
CAUTION:
Do not drain the gearbox fluid from the removed drive unit. Return the drive unit to MRB with the fluid intact for analysis. Transfer the halfshaft caps from the new drive unit to the removed drive unit to prevent spillage.
