Module - Steering Column Control - Remove And Replace: Notes

Last modified: 30/11/2023 01:37:51

Courtesy of TESLA, INC.

NOTE: See Personal Protection to make sure proper PPE is worn when performing the below procedure.

2023-11-30: Replaced Toolbox routine "PROC-VCLEFT_X_STEERING-COLUMN-CALIBRATION" with "PROC_STEERING_COLUMN_CALIBRATION".
2023-09-28: Updated steps per latest time study. The upper steering column shroud, steering column gap hider, and other IP trims no longer need to be removed.
2023-08-28: Added part number for the harness retaining clip.

WARNING: This procedure is a DRAFT, although it has been validated. Warnings and Cautions might be missing. Follow safety requirements and use extreme caution when working on or near high voltage systems and components. Provide corrections and feedback to ServiceDevelopment@teslamotors.com.
