Torque Specifications - Infotainment

TORQUE SPECIFICATIONS - AMPLIFIER, AUDIO, EXTERNAL (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolt that attaches the amplifier to the vehicle	5.4 N.m (4.0 ft-lbs)	10 mm deep socket Flex head ratchet	Reuse
Nuts that attach the amplifier to the vehicle	5.4 N.m (4.0 ft-lbs)	10 mm deep socket Flex head ratchet	Replace

TORQUE SPECIFICATIONS - ANTENNA, MIMO (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolt that attaches the MIMO antenna to the body	10 N.m (7.4 ft-lbs)	Torx Plus IP30 socket	Reuse

TORQUE SPECIFICATIONS - SPEAKER, FRONT DOOR, LH (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Screws that attach the front door speaker to the door	4 N.m (2.9 ft-lbs)	8 mm socket 1/4 in std ratchet 1/4 in torque wrench (installation only) 2 in extension	Reuse

TORQUE SPECIFICATIONS - TOUCHSCREEN (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace
Display housing to touchscreen fasteners	3 N.m (2.2 ft-lbs)	Torx T30 socket 1/4 in std ratchet 1/4 in torque wrench (installation only) 2 in extension	Replace
Instrument panel to touchscreen fasteners (10 mm hex)	16 N.m (11.8 ft-lbs)	10 mm socket 1/4 in std ratchet 1/4 in torque wrench (installation only) 4 in extension	Replace
Instrument panel to touchscreen fastener (T30 Torx)	12 N.m (8.8 ft-lbs) Courtesy of TESLA, INC.	Torx T30 socket 1/4 in std ratchet 1/4 in torque wrench (installation only) 4 in extension

TORQUE SPECIFICATIONS - USB HUB, CENTER CONSOLE, FRONT (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolts that attach the USB hub to the center console	1.1 N.m	Torx T20 socket 4 in extension	Reuse
