Model Coverage

MODEL COVERAGE

Model Body Engine (1) Engine ID Fuel(2) System Ignition System(5)
Camry SV 2.0L 4-Cyl.(3S-FE) S PFI Magnetic
" VZV 2.5L V6(2VZ-FE) V PFI Magnetic
Celica ST, GT 2.0L 4-Cyl.(3S-FE) S PFI Magnetic
" GT-S 2.0L 4-Cyl.(3S-GE) S PFI Magnetic
" ST (4WD) 2.0L 4-Cyl.(3S-GTE) S PFI Turbo Magnetic
Corolla AE 1.6L 4-Cyl.(4A-F) A 2-Bbl. Carb Magnetic
" AE(4WD) 1.6L 4-Cyl.(4A-FE) A PFI(6) Magnetic
" AE 1.6L 4-Cyl.(4A-GE) A PFI Magnetic
Cressida MX 3.0L 6-Cyl.(7M-GE) M PFI Magnetic
Land Cruiser FJ 4.0L 6-Cyl.(3F-E) F PFI Magnetic
MR2 AW 1.6L 4-Cyl.(4A-GE) A PFI Magnetic
Pickup RN 2.4L 4-Cyl.(22R) R 2-Bbl. Carb.(3) Magnetic
" RN 2.4L 4-Cyl.(22R-E) R PFI Magnetic
" VZN 3.0L V6 (3VZ-E) V PFI Magnetic
Supra MA 3.0L 6-Cyl.(7M-GE) M PFI Magnetic
" MA 3.0L 6-Cyl.(7M-GTE) M PFI Turbo DIS(4)
Tercel EL 1.5L 4-Cyl.(3E) E 1-Bbl. Carb.(3) Magnetic
Van YR 2.2L 4-Cyl.(4Y-E) Y PFI Magnetic
4Runner RN 2.4L 4-Cyl.(22R-E) R PFI Magnetic
" VZN 3.0L V6 (3VZ-E) V PFI Magnetic
(1) Engine may be identified by the Vehicle Identification Number (VIN) or number stamped on engine block. VIN is located on stamped plate on left side of instrument panel. VIN is also found in other locations. See Figure.
(2) PFI is port fuel injection.
(3) Computer controlled feedback carburetor.
(4) Distributorless ignition system.
(5) All except carbureted vehicles have computer controlled ignition timing advance.
(6) Uses "D" Jetronic type PFI with Manifold Air Pressure (MAP) Sensor.
