| Body Electronic Control Unit (ECU) |
Behind Center Of Instrument Panel |
| Engine Room Junction Block |
Left Side Of Engine Compartment |
| Headlight Relay |
In Engine Room Junction Block |
| Key Unlock Warning Switch |
On Ignition Lock Cylinder Housing |
| Left Junction Block (Driver's Side Fuse/Relay Box) |
Behind Left Kick Panel |
| Park/Neutral Position (PNP) Switch (A/T Indicator Light Switch) |
On Right Side Of Transmission |
| Power Main Relay |
In Left Junction Block |
| Stoplight Switch |
Top Of Brake Pedal |
| Taillight Relay |
In Left Junction Block |
