Front Shock Absorber With Coil Spring: Disposal

DISPOSE OF SHOCK ABSORBER ASSY FRONT LH
1. Fully extend the shock absorber piston rod.
2. Using a drill, make a hole in the cylinder as shown in the illustration to discharge the gas inside.
CAUTION:
- When drilling, chips may fly out, work carefully.
- The gas is colorless, odorless and non-poisonous.
Fig 1: Identifying Area In Cylinder For Drilling Hole
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
