DTC P0441 Evaporative Emission Control System Incorrect Purge Flow: Wiring Diagram

Fig 1: Leak Detection Pump - Wiring Diagram
G05188747Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Leak Detection Pump - Wiring Diagram
G05188748Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
