Throttle Body: Components: Illustration

Fig 1: Identifying Throttle Body Replacement Components With Torque Specifications (1 Of 2)
GTY341788Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002


Fig 1: Identifying Throttle Body Replacement Components With Torque Specifications (2 Of 2)
GTY227926Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
