Carphone antenna/GPS antenna

Fig 1: Identifying Carphone Antenna/GPS Antenna

Courtesy of VOLVO CARS OF NORTH AMERICA.

The GPS and carphone antennas are directly connected to the phone module (PHM). The antennas are in the front windshield in front of the rear view mirror.

There are diagnostics for both the GPS and carphone antennas.
