Install continued

Fig 1: Identifying Camshaft Components

Courtesy of VOLVO CARS OF NORTH AMERICA.

Install:

• the cover over the ignition coils.

  Tightening torque 8 Nm (6 lb. ft)  .

• the upper camshaft belt cover.

  Tightening torque 8 Nm (6 lb. ft)  .

• the disassembled connectors.

Applies only to turbocharged engines:

Install the charge air pipe.

Remove the seals.

Tighten the mountings and hose clamps.
