Climate Control Switch Removal/Installation

WARNING: This page is about a different car, the 2011 Acura TL, 2010 Acura TL, and 2009 Acura TL. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the audio-navigation unit (with navigation) (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ), or the audio unit (without navigation) (see AUDIO UNIT REMOVAL/INSTALLATION )
  2. Remove the self-tapping screws and the climate control switches (A)
    Fig 1: Identifying Climate Control Switches And Self-Tapping Screws
    G05988710Courtesy of AMERICAN HONDA MOTOR CO., INC.
  3. Install the control switches in the reverse order of removal After installation, operate the various functions to make sure they work properly
