USB Memory Information

If the USB memory is connected to the USB port, the screen displays the USB memory size, the Product ID, Vender ID, and connection status.

If Connection shows NG, Check for poor connections or loose terminals at audio-navigation unit connector K (7P).

Fig 1: Screen Display - USB Memory Information
G08077705Courtesy of AMERICAN HONDA MOTOR CO., INC.
