Switch-DECKLID Release 2 (Base) Connector End View (D2256A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 1/11925/97

Part Description: Not Available

Connector No: D2256A

Option: BASE

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Switch-Decklid Release 2 Connector End View (BASE)

Courtesy of CHRYSLER

Fig 2: Switch-Decklid Release 2 Component Location (BASE)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P31

WH/OG

0.35

DECKLID/LIFTGATE RELEASE DRIVER

EXCEPT KEYLESS IGNITION

Z341

0.35

GROUND

EXCEPT KEYLESS IGNITION

⁽¹⁾	Pins not listed are not used for this connector
