Module-Adaptive Cruise Control (Standard) Connector End View (D3098A)

Harness-Family: Headlamp_Dash

Color: BLACK

Gender: FEMALE

Part Number: 1/14841/97

Part Description: Not Available

Connector No: D3098A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Adaptive Cruise Control Connector End View (Standard)
GCWD1205162Courtesy of CHRYSLER
Fig 2: Module-Adaptive Cruise Control Component Location (Standard)
GCWD1267413Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 Z101 BK 0.75 GROUND LANE DEPARTURE
2 D11 GN 0.35 CAN C (+) 2.0L/2.2L
3 D12 BN 0.35 CAN C (-) 2.0L/2.2L
5 D469 GN 0.35 PRIVATE CAN (+) LANE DEPARTURE
6 D468 BN 0.35 PRIVATE CAN (-) LANE DEPARTURE
8 F741 DB/RD 0.75 IGNITION RUN/START OUTPUT LANE DEPARTURE
(1) Pins not listed are not used for this connector
