Module-Body Control C2 (2.0L/2.2L) Connector End View (D2762B)

Harness-Family: Headlamp_Dash

Color: BLUE

Gender: FEMALE

Part Number: 1/01497/82

Part Description: Not Available

Connector No: D2762B

Option: 2.0L/2.2L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Body Control C2 Connector End View (2.0L/2.2L)

Courtesy of CHRYSLER

Fig 2: Module-Body Control C2 Component Location (2.0L/2.2L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A901

6.0

FUSED B(+)

2.0L/2.2L

⁽¹⁾	Pins not listed are not used for this connector
