Module-Body Control C5 (Standard) Connector End View (D2762E)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 1/15937/07

Part Description: Not Available

Connector No: D2762E

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Body Control C5 Connector End View (Standard)
GCWD1233295Courtesy of CHRYSLER
Fig 2: Module-Body Control C5 Component Location (Standard)
GCWD1267890Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 P33 WH/BK 1.5 DOOR LOCK DRIVER N/A
2 A901 RD/GN 2.5 FUSED B(+) N/A
3 P1 OG/GN 1.5 DOOR UNLOCK DRIVER N/A
4 A901 RD/YE 0.75 FUSED B(+) N/A
6 M1 VT 0.5 COURTESY LAMPS DRIVER N/A
7 E12 RD/GY 0.5 PANEL LAMPS DRIVER N/A
8 M5 RD/BK 0.5 SILL PLATE ILLUMINATION DRIVER N/A
9 A903 RD/BK 0.5 FUSED B(+) N/A
10 P372 BK 0.5 DOOR LOCK SW RTN PASS N/A
11 F741 DB 0.5 IGNITION RUN/START OUTPUT N/A
12 F741 DB/WH 0.75 IGNITION RUN/START OUTPUT BASE
14 A927 RD 2.5 FUSED B(+) N/A
15 A926 RD/BK 2.5 FUSED B(+) N/A
17 P306 VT 1.5 LIFTGATE UNLOCK DRIVER N/A
18 P1 OG/WH 1.5 DOOR UNLOCK DRIVER N/A
19 A901 RD/WH 2.5 FUSED B(+) N/A
21 A901 RD/GN 0.75 FUSED B(+) N/A
23 F926 DB/WH 0.5 FUSED IGNITION SWITCH OUTPUT (RUN) BASE
24 F926 DB 0.5 FUSED IGNITION SWITCH OUTPUT (RUN) N/A
25 F926 DB/BK 0.5 FUSED IGNITION SWITCH OUTPUT (RUN) SUNROOF
26 F741 DB/WH 0.5 IGNITION RUN/START OUTPUT N/A
27 F741 DB 0.5 IGNITION RUN/START OUTPUT EXPORT BASE/EXCEPT EXPORT
28 M59 VT 0.5 COURTESY LAMP FEED N/A
(1) Pins not listed are not used for this connector
